2-Post Hydraulic Freight Lift
The Naltako 2-post hydraulic freight lift is the optimal cargo lifting solution for narrow spaces. With a compact design that is easy to install and relocate, it is suitable for shops, supermarkets, and warehouses. Featuring a powerful hydraulic system and smooth operation, it ensures absolute safety for goods weighing up to 1 ton. Cost-effective and space-saving, the Naltako lift is a smart choice for every business.
What is a 2-post hydraulic freight lift?
A 2-post hydraulic freight lift is lifting equipment that utilizes a hydraulic system combined with pulling cables. This design helps lift goods smoothly, safely, and efficiently in factories, warehouses, construction sites, etc.
The 2 sturdy vertical posts are the main part of the lift, bearing the entire weight of the lifted object. Adjustable lifting arms or platforms are attached to the posts to lift goods between floors.
Structure
- 2 vertical posts
- Fluid reservoir
- Hydraulic pump
- Control valve
- Hydraulic cylinder
- Lifting platform
- Cable pulling system
Operating Principle
- The pump pushes hydraulic oil into the cylinder.
- Hydraulic oil pushes the piston, raising the lifting table.
- When the desired floor is reached, the valve closes, keeping the oil in the cylinder.
- To lower, the valve opens, and hydraulic oil flows back to the reservoir.
- The weight of the lifting table and goods pushes the piston down, returning hydraulic oil to the reservoir.
Reference:
Technical specifications of Naltako 2-post hydraulic freight lift
| General Specifications |
Technical Specifications
|
| Brand |
Naltako
|
| Name: |
2-Post Hydraulic Freight Lift
|
| Lifting capacity |
300kg, 500kg, 1000kg,…
|
| Max lifting height |
From 1m – 6m
|
| Table dimensions |
From 1m x 1m – 1.5m x 1.5m
|
| Power supply |
220V/50Hz or 380V/50Hz
|
| Motor power |
1.5kW – 3kW
|
| Lifting system |
Hydraulic, using 2 hydraulic cylinders and a hydraulic pump
|
| Control system |
Up/down buttons, remote control integration available
|
| Material |
Stainless steel or powder-coated steel
|
| Color |
Yellow, blue, or per customer request
|
Safety specifications:
- Hydraulic safety valve
- Mechanical lock
- Travel sensor
- Emergency stop button
Note:
The specifications of the hydraulic freight lift are for reference only; actual specifications may vary depending on the model and customer requirements.
Who is the 2-post hydraulic freight lift suitable for?
The 2-post lift using a hydraulic system is suitable for those who need a simple, convenient, cost-effective, and space-saving freight lifting solution, especially in narrow spaces.
- Shops, supermarkets;
- Manufacturing workshops;
- Car and motorbike garages;
- Small warehouses;
- Individuals, families, small businesses.
Contact Naltako immediately for consultation and detailed quotation:
- Website: https://naltako.vn/
- Hotline: 0981.977.898
- Email: nhat.mtk53@gmail.com
- Workshop address: Dong De Village, Phu Yen, Chuong My, Hanoi.
