Are you facing difficulties in loading and unloading goods? Do high labor costs for handling affect your business profits? Use a loading dock as the optimal solution for these issues.

NỘI DUNG BÀI VIẾT

What is a Loading Dock?

A loading dock, also known as a dock leveler, is a device used to connect the warehouse with the truck bed, allowing trucks to easily move up and down and load/unload goods safely and efficiently.

Loading docks operate based on the principle of hydraulic lifting, helping to raise and lower the dock platform flexibly, suitable for the height of the truck bed.

Structure of a Loading Dock

A loading dock consists of 4 main parts:

Lifting system: Hydraulic lifting system.
Platform: The part that directly contacts the forklift.
Dock frame: The frame bearing the entire load of the goods and the dock equipment.
Lip: Also known as the lip plate, attached to the dock floor, helping the forklift move up and down easily.

Apart from the above parts, the loading dock also has a safety system and rubber bumpers to ensure safety for operators and goods.

Working Principle of the Loading Dock

The loading dock operates based on the hydraulic principle. When lifting, the hydraulic pump pumps oil into the hydraulic cylinder, creating an upward force on the piston. When lowering, the system opens the safety valve lock and lowers the platform.

Technical Specifications of the Loading Dock

Hydraulic dock platform specifications depend on the customer’s lifting needs. Here are some product specifications you can refer to:

Dimensions:

Length: 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, 4000mm
Width: 2000mm
Height: 600mm
Dock Pit: 1800x2000mm

Capacity: 6-ton Dock Leveler, 8 tons, 10 tons, 12 tons, 15 tons

Lifting system: hydraulic

Lip: 500mm

Steel thickness: 6mm, 8mm, 10mm

Power supply: 220V/380V

Note that the above parameters are for reference only and may vary by manufacturer. Please contact the supplier for specific advice.

Benefits of the Loading Dock

Improve efficiency and productivity in loading and unloading goods: The loading dock helps trucks move up and down quickly and easily, thereby saving time and labor for loading and unloading goods.

Minimize damage to goods: The device creates a flat surface connecting the warehouse and the truck bed, thereby minimizing collisions and damage to goods during loading and unloading.

Protect forklifts: The truck loading dock helps forklifts move directly onto the truck bed without using a loading bridge, thereby protecting the forklift from damage.

Loading Dock Price

Loading dock prices depend on factors including: Design requirements, size, capacity, brand… You should contact loading dock suppliers directly for advice and detailed quotes.

Reputable Loading Dock Seller

Naltako is a unit specializing in providing reputable hydraulic lifting equipment and industrial lifting equipment in Vietnam. With over 7 years of experience in this field, Naltako has affirmed its position in the market and become a reliable partner of many businesses.

We are also a direct manufacturing, designing, installing, warranty, and maintenance unit, so we will have the best price.

Naltako commits:

Provide genuine, high-quality loading docks at competitive prices.
Team of highly qualified engineers, free consultation, and attentive customer support.
Professional installation, warranty, and maintenance services for loading and unloading docks.
