8-ton Hydraulic Dock Leveler with 2x2m Deck
The 8-ton hydraulic dock leveler with a 2x2m deck ensures rapid and safe cargo loading and unloading, enhancing efficiency for your business. Manufactured in Vietnam using high-grade steel, this dock leveler guarantees durability and user safety. The control system is easy to operate and integrates multiple safety features. The product comes with a 2-year warranty, lifetime maintenance, and nationwide support for shipping and installation.
✔️ Load capacity: 8 tons
✔️ Deck dimensions: 2x2m
✔️ Lip dimensions: 400x2000mm
✔️ Lifting range: 300 – 700mm
✔️ Power: 0.75kW
✔️ Overall dimensions: 2500x2040x600mm
Key features of the 8-ton hydraulic dock leveler with a 2x2m deck
Compared to the 8000kg Dock Leveler with a 2.5x2m deck, the 2x2m deck model features a compact size, making it suitable for limited installation spaces and the lifting of small to medium-sized goods. In particular, this product offers a lower cost and lighter weight, facilitating easier transportation and installation.
If installation space is limited and you mainly handle small to medium-sized goods, the 2x2m dock leveler will be a suitable choice.
Technical Specifications
| Parameter | Reference Value | Note |
| Load capacity | 8 tons | |
| Type | Standard hydraulic dock leveler | |
| Deck dimensions | 2000 x 2000 mm (2x2m) | |
| Lip dimensions | 400 x 2000 mm | |
| Lifting range | 300 – 700 mm |
Adjustable according to actual needs
|
| Motor power | 0.75 kW | |
| Overall dimensions | 2500 x 2040 x 600 mm (Length x Width x Height) | |
| Lifting stroke | 400 mm |
Distance the deck moves from the lowest to the highest position
|
| Lifting time | ~ 20 – 30 seconds |
Time for the dock leveler to complete the full lifting stroke
|
| Max tilt angle | ~ 12 degrees |
Safe tilt angle for forklifts moving onto the deck
|
| Working pressure | ~ 16 MPa |
Hydraulic oil pressure in the system
|
| Oil flow rate | ~ 8 liters/minute | |
| Voltage | 380V/50Hz |
Or 220V depending on requirements
|
| Hydraulic oil type | Hydraulic oil AW 46 | |
| Self-weight | ~ 1500 kg | |
| Deck material | Anti-slip checkered plate | Thickness 6-8mm |
| Frame material | U, I shaped steel | |
| Control system | Push button |
Remote control integration available
|
| Safety standards | EN 1570, ASME B20.1 |
Ensures safety for operators and goods
|
Where to buy a reputable 8-ton hydraulic dock leveler with a 2x2m deck?
Naltako is the provider of high-quality 8-ton hydraulic dock levelers with 2x2m decks, meeting all your cargo lifting needs.
The Dock leveler is manufactured directly in Vietnam, bringing outstanding benefits:
✔️ Eliminates import costs, helping to optimize investment costs for businesses.
✔️ Designed and manufactured based on Vietnam’s climate conditions, environment, and usage habits, ensuring durability and optimal operating efficiency.
✔️ Replacement parts are readily available, helping to save time and maintenance costs.
✔️ Domestic technical team ready to support and troubleshoot issues promptly.
In addition, Naltako is committed to quality and dedicated service:
✔️ 2-year product warranty and lifetime maintenance, providing absolute peace of mind for customers.
✔️ Free shipping support in the North and Central regions, 50% shipping cost support for the South region.
| Weight | 1500 kg |
|---|---|
| Dimensions | 2500 × 2040 × 600 cm |
