8-Ton Dock Leveler

What is an 8-ton dock leveler?

The 8-ton dock leveler is a type of hydraulic dock leveler with a maximum load capacity of 8000 kg. This device is widely used in warehouses, factories, and yards to connect the warehouse floor with the floor of trucks and containers.

The 8-ton type dock leveler can be raised and lowered flexibly, helping forklifts move easily, safely, and quickly when there is a height difference between the warehouse floor and the truck floor.

To perform the lifting and lowering operations, the device is equipped with a hydraulic system based on Pascal’s law. When the hydraulic pump is activated, it creates high pressure in the system. This pressure is then transmitted through the control valve to the hydraulic cylinder, thereby pushing the piston up vertically. The lowering operation is performed in reverse.

Specifications of the 8-ton hydraulic dock leveler

Manufacturer name: Naltako Industrial Joint Stock Company

Maximum load: 8 tons (8000 kg)

Dimensions (Length x Width x Height):

• 2440 x 1830 x 600 mm (length x width x height)
• 2500 x 1830 x 600 mm (length x width x height)
• Dimensions can be customized according to usage needs.

Front lip (Length x Width):

• Common dimensions: 400 x 1830 mm (length x width)
• The front lip helps cover the gap between the dock leveler and the truck, ensuring safety for users and goods.

Lifting height:

• Common lifting height: 400 – 600 mm
• Necessary lifting height depends on the height of the warehouse floor and the truck floor.

Lowering height:

• Common lowering height: 300 – 400 mm
• Necessary lowering height depends on the height of the truck when not yet raised.

Lifting system: Hydraulic

Power source: 3-phase

Material: SS400 structural steel

Color: According to customer requirements

Advantages and limitations of the 8-ton dock leveler

Advantages

The dock leveler has high applicability and is commonly used in warehouses with a moderate forklift fleet and average cargo weight.

Due to the load not being too large, the product is cheaper than the 12-ton dock leveler, saving costs for businesses.

The 8-ton hydraulic dock leveler has an average size, suitable for businesses with moderate goods transport and production needs.

Limitations

Compared to the 6-ton dock leveler, this device has a higher cost, consumes more power, and has more limited mobility.

Who is the 8-ton dock leveler suitable for?

The 8-ton Dock Leveler is suitable for businesses or logistics operations with moderate goods transport needs as well as manufacturing facilities with cargo loading/unloading processes that want to accelerate product delivery to customers.

• Manufacturing and trading enterprises: Including manufacturing plants, warehouses, and product distribution centers.
• Logistics centers: Warehouses, goods sorting centers.
• Yards, ports: Essential equipment at container terminals, truck stations, and seaports supporting loading and unloading goods to boost import-export activities.
• Additionally, the 8-ton Dock Leveler is also applied in other industries such as auto repair and maintenance workshops, supermarkets, etc.

Reputable and good-priced 8-ton Dock Leveler Brand

With over 7 years of experience in the field of providing lifting equipment, Naltako is proud to be a top reputable unit in providing high-quality, competitively priced 8-ton Dock Levelers.

Why choose Naltako?

Highly specialized engineering team: Naltako possesses a team of experienced engineers with deep understanding of the Dock Leveler field, always ready to advise and support customers in choosing the most suitable product.

Full-package service: Naltako provides full-package services from design, production, installation, maintenance to transporting products to customers.

Attractive warranty policy: Naltako offers a 2-year warranty for 8-ton Dock Leveler products and lifetime maintenance.

Shipping support: Naltako supports 50% – 100% of shipping costs for customers nationwide.

Price of 8-ton dock leveler at Naltako

We provide many different models of 8-ton hydraulic dock levelers with different features and sizes. Each model may have a different price. To get the most accurate quote for an 8-ton hydraulic dock leveler suitable for your needs, please contact Naltako directly via the following channels:

Website: https://naltako.vn/

Hotline: 0981.977.898

Email: nhat.mtk53@gmail.com

Workshop address: Dong De Hamlet, Phu Yen, Chuong My, Hanoi.
