Specifications of 6-ton Dock Leveler 2.5x2m Deck

Specifications	Details
Load Capacity	6 tons (6000kg)
Platform Dimensions	2500×2000 (2.5x2m)
Dimensions (LxWxH)	2500x2000x510mm
Front Lip (LxW)	1750x400mm
Lifting Height (A)	+450mm
Lowering Height (B)	-300mm
Material	Steel
Cable Tray	1370mm
Rear Frame	H= 500mm
Max Gradient	12.5%
Platform Length	2500mm
Platform Width	2000mm
Lip Length	1750mm
Lip Width	400mm
Lip Thickness	12-14mm
Deck Thickness	10-12mm
Hydraulic Pump	Gear hydraulic pump: 7-8 liters/minute
Hydraulic Cylinder	02 lifting cylinders – 01 deck lifting cylinder: dia 100 – 01 lip lifting cylinder: dia 50
Hydraulic Source	Hydronit – Italy
Working Pressure	180 bar
Motor Power	3 kW
Oil Flow Rate	7-8 liters/minute
Oil Tank Capacity	20-25 liters
Hydraulic Oil Type	ISO VG 46
Control	Push button
Control Cabinet	Assembled by Naltako (01 cabinet/set) – Input: 380V – Control voltage: 220V
Accessories	Rubber bumpers – 2 pieces/set – Copper pipes, wiring, installation accessories
Other Specs
Weight	1000 kg
Paint Color	Yellow (or as requested)
Warranty	12 months
Origin	Vietnam

Key Features

The Dock Leveler has a lifting capacity 1 ton greater than the 5-ton Dock Leveler, with a 2×1.8m deck, allowing for the lifting of heavier goods and meeting diverse cargo handling needs.

The device features a platform size of 2.5x2m, wider than the 5-ton version (2×1.8m), creating a comfortable maneuvering space for forklifts and increasing work efficiency.

The lifting platform is designed with a stronger structure, increasing durability and load-bearing capacity, ensuring stable and safe operation when lifting heavy goods.

The dock’s hydraulic system is upgraded with a high-capacity hydraulic pump (7-8 liters/minute), large-diameter hydraulic cylinders (dia 100 and dia 50), and high working pressure (180 bar). The oil tank capacity is also increased (20-25 liters). These improvements help lift and lower goods quickly, smoothly, and more efficiently.

Applications of 6-ton Dock Leveler 2.5x2m Deck

The 6-ton Dock Leveler with a 2.5x2m deck is widely applied in industrial and logistics sectors thanks to its large load capacity and spacious dimensions.

Heavy Industry:

Lifting heavy components in automotive manufacturing.
Handling heavy machinery and equipment.
Transporting construction materials (bricks, cement, steel).

Logistics and Warehousing:

Lifting goods at warehouses and distribution centers.
Transporting container cargo at ports and airports.
Receiving and transporting goods at supermarkets and shopping malls.

Other Industries:

Handling goods in beverage production.
Transporting raw materials and products in food processing.
Lifting equipment and raw materials in pharmaceutical production.

Where to buy 6-ton Dock Leveler, 2.5x2m deck

If you are interested in this useful product, Naltako is the manufacturer of the 6-ton Dock Leveler, 2.5x2m deck right here in Vietnam. In addition to standard load capacity and dimensions, customers can choose to add or remove features to suit their budget and working conditions.
