Wood Chip Truck Dumper

Reference Technical Specifications for Wood Chip Truck Dumper

General Specifications

• Platform dimensions: 18.5m (length) x 3.6m (width)
• Max tipping angle: 55 degrees (suitable for wood chips)
• Lifting speed: ~4 minutes
• Lowering speed: ~4 minutes
• Design lifting capacity: 80 tons (including vehicle weight)
• Actual lifting capacity: 100 tons (including vehicle weight)

Hydraulic System Specifications

• Hydraulic cylinders: 02 sets (or more depending on load)
• Hydraulic power unit:
  • Oil capacity: 900L
  • Motor power: 18.5KW
  • Pump flow rate: 54 L/min
• Working pressure: 170 Bar

Structure

• Material: Steel fabricated in Vietnam (ensuring quality and durability)
• Control system:
  • Control panel with buttons/levers
  • Integrated safety system (overload sensors, safety valves, etc.)
• Safety features:
  • Hydraulic safety valve
  • Mechanical anti-fall lock
  • Operation alarm siren
  • Safety fencing around the operation area

Note:

The above specifications are for reference only. Parameters such as lifting/lowering speed may vary depending on the actual load and hydraulic system design.

Applications of Wood Chip Truck Dumper

Application in wood and paper manufacturing plants

The dumper helps discharge wood chips from trucks onto conveyor systems or into storage warehouses, providing raw materials for plywood or paper production processes.

The equipment helps supply wood chips or wood scraps continuously and stably for pulp production, ensuring productivity and product quality.

Application in the wood import/export industry

The dumper helps discharge wood materials from trucks onto cargo ships or transport systems quickly and efficiently, reducing waiting time and increasing cargo handling productivity.

Application in logistics

The equipment is used to discharge wood chips from trucks into silos or large storage tanks. This activity helps optimize storage space and minimizes direct worker contact with wood chips, ensuring occupational safety.
