Superior construction of the 900kg mini crane

To understand why the 900kg mini crane is so durable and effective, we need to examine its detailed structure. This mini crane is optimized for flexibility and power:
- Chassis and Base: The entire chassis is made from high-strength load-bearing steel, coated with electrostatic powder to resist rust and abrasion. The sturdy base design comes with 2 adjustable outriggers, enhancing absolute stability when lifting heavy loads.
- Hydraulic Lifting Boom: This is the most critical part of the 900kg mini crane, utilizing powerful hydraulic cylinders to allow for smooth reaching and lifting. The boom can be folded neatly when not in use.
- Electric Motor and Battery System: Utilizing a large-capacity battery power source helps the crane operate quietly, without noise emissions or toxic fumes. This makes it ideal for indoor working environments and clean warehouses.
- Smart Control System: The device integrates a travel control handle (similar to an electric pallet stacker) and a remote control unit. This allows the operator to stand at a distance to observe and perform lifting, lowering, and boom extension operations, ensuring maximum safety.
- Crane Hook and 240-degree Rotation Capability: Standard safety crane hook (with latch). Notably, the body of the 900kg mini crane has the ability to rotate 240 degrees, allowing for picking up and placing goods in any position around it without moving the entire vehicle.
Detailed Technical Specifications
Below is the standard technical specification table of the 900kg mini crane model distributed by Naltako, giving customers the clearest view before deciding to invest:
| Attribute | Detailed Specifications |
| Model | EPFC |
| Lifting capacity | 1200 kg |
| Load center distance | 600 mm |
| Ground clearance | 25 mm |
| Wheelbase | 1400 mm |
| Vehicle dimensions | |
| Overall length | 1930 x 766 x 1300 mm |
| Fork dimensions (length x width x thickness) | 1150 x 175 x 60 mm |
| Overall width over forks | 550 mm |
| Max lifting height | 120 mm |
| Tiller height (lowered) | 85 mm |
| Tiller height (raised) | 1420 mm |
| Head dimensions (length x width x height) | 780 x 720 x 792 mm |
| Turning radius | 1720 mm |
| Minimum aisle width | 800 mm |
| Wheels | |
| Support wheels | 76 x 36 mm |
| Front wheels (Load wheels) | Single 85 x 112 mm |
| Driving wheels | 250 x 80 mm |
| Performance | |
| Lifting speed (laden / unladen) | 35 mm/s / 40 mm/s |
| Lowering speed (laden / unladen) | 50 mm/s / 25 mm/s |
| Travel speed (laden / unladen) | 3.5 – 4 km/h / 4.2 km/h |
| Gradeability (laden / unladen) | 5% / 10% |
| Motor and Electric | |
| Drive motor | 24V / 1200W |
| Lift motor | 24V / 2000W |
| Controller | MOS-FET |
| Battery | 2 x 12V / 160Ah |
| Battery charger (External) | AC 220V/50HZ (or AC 110V/60HZ) – Output 24V/40A |
| Weight | |
| Service weight (including battery) | 658 kg |
Note: Specifications of the 900kg mini crane may vary depending on the model and specific upgrade requests of customers at Naltako.
Naltako – The address for supplying quality and reputable 900kg mini cranes
There are many units supplying lifting equipment on the market, but Naltako proudly stands as the top reputable address to buy quality 900kg mini cranes. We understand that investing in machinery is an important decision, so Naltako commits to:
- Genuine products: 100% equipment imported directly from the manufacturing factory, with full CO (Certificate of Origin) and CQ (Certificate of Quality) documents.
- Competitive prices: As a direct distributor, we bring the best price for a 900kg mini crane without going through any intermediaries.
- Golden warranty policy: Long-term warranty (12-24 months), 24/7 technical support, and genuine spare parts are always available for replacement and repair when needed.
- In-depth consultation: Naltako’s technically knowledgeable engineering team will survey and consult on the exact crane model most suitable for your factory’s specific needs.
Choosing Naltako means choosing peace of mind, efficiency, and dedicated after-sales service.
Conclusion
Mobility, 900kg lifting power, 360-degree rotation capability, and quiet electric operation have made the 900kg mini crane a smart investment, bringing long-term economic benefits. It is not just a tool, but a comprehensive solution to liberate labor, increase productivity, and ensure safety for lifting tasks in narrow spaces.
To receive a quote and direct consultation about this superior mini crane model, please contact Naltako immediately via Hotline 0981.977.898. Our team is always ready to serve!
