1.5-Ton Mobile Dock Leveler

Introduction to 1.5-Ton Mobile Dock Leveler

The 1.5-ton mobile dock leveler or 1.5-ton mobile lifting platform (Moveable Hydraulic Dock Leveler) is an equipment that supports efficient and safe cargo loading and unloading. With a lifting capacity of 1.5 tons and a maximum lifting height of 1600mm, this product can meet the diverse loading and unloading needs of small and medium-sized enterprises.

The 1.5-ton mobile dock leveler is a variation of the traditional dock leveler, helping to connect the height gap between trucks/containers and the ground or warehouse floor effectively and safely.

The biggest advantage is its high mobility. You can easily move the lifting platform to any necessary position in the warehouse or workshop to serve cargo loading and unloading at many different points.

In addition, the price and initial investment cost of the 1.5-ton mobile dock leveler are also much cheaper than fixed dock levelers of the same capacity, so it is chosen by many businesses and individuals.

The product can be used for many types of trucks and containers with different floor sizes and heights thanks to its flexible height adjustment capability.

Structure and Operating Principle of 1.5-Ton Mobile Dock Leveler

Structure

Lifting Platform: Made of anti-slip chequered steel plate, with optimal thickness to ensure durability and load-bearing capacity.

Hydraulic Lifting System: Consists of hydraulic cylinders, hydraulic pump, control valve, and oil pipelines.

Platform Frame: Sturdy load-bearing steel frame structure, carefully calculated to optimize weight and load-bearing capacity.

Wheels: Includes 4 high-load PU wheels (2 fixed and 2 swivel with brakes).

Flip Plate (Lip): The dock leveler has 2 steel lips on both sides of the platform. The lips are connected to the platform by hinges and can be flipped up and down to create a ramp connecting the platform to the truck floor. The wheels supporting the lip help it move smoothly during lifting and lowering.

Control System: The control box is placed in front of the dock leveler, including buttons or switches to control the platform lifting/lowering and lip operation.

Power Unit: The power unit supplies electricity to the hydraulic motor and control system.

Operating Principle

1. Moving: Use wheels to move the dock leveler to the working position, close to the truck edge.
2. Lowering the ramp: Lower the 2 lips to create a ramp connecting the platform to the truck floor.
3. Lifting/Lowering: Operate the hydraulic system via the control box to raise the platform to a height suitable for the truck floor.
4. Loading/Unloading: Use hand pallet trucks or electric forklifts to move goods onto the platform, then into the truck or vice versa.
5. Retracting the ramp: After finishing work, lower the platform and flip the 2 lips up.
6. Moving: Move the dock leveler away from the working position.

Technical Specifications

Applications of 1.5-Ton Mobile Dock Leveler

The 1.5-ton mobile dock leveler, thanks to its superior flexibility compared to fixed types, offers diverse applications in industrial and logistics sectors.

• Warehousing: Loading/unloading goods from trucks to shelves, pallets or vice versa.
• Manufacturing: Lifting materials, semi-finished products in production lines.
• Construction: Lifting construction materials, equipment to upper floors.
• Logistics: Loading/unloading goods at distribution centers, transit warehouses.
• Repair & Maintenance: Lifting equipment, machinery for repair and maintenance.

Price of 1.5-Ton Mobile Dock Leveler

The selling price of the 1.5-ton mobile dock leveler ranges from 50 million to 150 million VND. The price also depends on many factors such as materials, features, lifting height…

For accurate price information, please contact us directly: Hotline: 0981 977 898 – 0986 868 003
